EOS Econ D2

Control unit, dry Finnish sauna

Electronic sauna control unit for private and commercial use.

Electronic sauna control unit for the dry (Finnish) sauna with a large LCD display with multi-language menu navigation. Universal model suitable for private and commercial use.

Control range between 30 °C and 115 °C. Safety temperature limiter, 139 °C. Inc. temperature sensor with 2 m cable.

Additionally with: Extra-large, multi-line LCD display, all parameters at a glance. With 24 h pre-set timer in real time, heating time limitation up to 6 h or up to 12 h (for commercial use). 4 user profiles.

Switching power 9 kW, may be extended for connection of more powerful heaters.

Item no.
946138



  • Illuminated extra-large multi-line LCD display, shows all parameters at a glance. Menu navigation in 12 languages.
  • Suitable for commercial operation.
  • 24 h pre-set timer in real time, clock, screen-saver function.
  • Switch for cabin light, “Life Guard” function.
  • Heating time limitation 6 h, extendable to12 h.
  • Switching capacity 9 kW, may be extended with an LSG device.

Electrical connection

400 V 3N ~ 50 Hz

Switching capacity

9,0 kW resistive load

Power extension via LSG unit

LSG 10 / LSG 18 / LSG 36

Temperature control range

30 - 115 °C

Start time pre-selection

up to 24 hrs

Cabin light/fan outputs

max. 100 W

Heating time limitation

6 hrs or 12 hrs

Dimensions H/W/D in cm

22 / 25 / 6,7

Ambient temperature in operation

-10 to +40 °C

Weight without packaging

1,0 kg
